SS304 Flexible Mesh for Refractory Lining, 1.5X25mm strips, 25mm hole, 3.0mm steel rod, 1x1m, HESLY China Factory sales

$China SS304 Flexible Mesh for Refractory Lining, 1.5X25mm strips, 25mm hole, 3.0mm steel rod, 1x1m, HESLY China Factory sales supplier$

$SS304 Flexible Mesh for Refractory Lining, 1.5X25mm strips, 25mm hole, 3.0mm steel rod, 1x1m, HESLY China Factory sales supplier$

Large Image : SS304 Flexible Mesh for Refractory Lining, 1.5X25mm strips, 25mm hole, 3.0mm steel rod, 1x1m, HESLY China Factory sales

Product Details:

Place of Origin:	Hesly Metal Mesh, CHINA
Brand Name:	HESLY
Certification:	ISO9001：2008
Model Number:	HEX152536304F

Payment & Shipping Terms:

Minimum Order Quantity:	50 SQM
Price:	US$ 30.00 to 260.00/sq.m
Packaging Details:	Pallet
Delivery Time:	15days
Payment Terms:	TT/LC
Supply Ability:	500㎡/day

Contact Now

Detailed Product Description

Material:	SS304	Strips:	25X1.5mm
Hole:	37mm	Dimension:	1x1m

SS304 Flexible Mesh for Refractory Lining, 1.5X25mm strips, 25mm hole, 3.0mm steel rod, 1x1m, HESLY China Factory sales

HESLY hex metal, hex mesh & hexsteel, your best choice for Anchoring & Reinforcement for Refractories and Concrete Flooring !!!

Flexible Metal Mesh

Flexible metal refractory lining is the direct counterpart of hex metal, it performs all the same functions of reinforcement of thin wall refractory linings, while its design allows free form rolling to very small diameters. Hex metal becomes impractical to use when the section of plant being protected is of small diameter, the free rolling capabilities of flex metal allows plant as small as 150mm to lined. Typical applications include air distributors, cyclone diplegs, fan cases and all plants where the practicality of free rolling material is beneficial to maintenance activities

$flexible mesh Refractory lining$
Standard Flexible Mesh	Flexible Mesh With Lances

Flexible Mesh Application

Raw Material Typical Service Temperature

Anchorage Material		Chemical Composition								Typical Service Temperature
AISI	DIN	C%	Si%	Mn%	P%	S%	Cr%	Ni%	others	Typical Service Temperature
304	1.4301	≤0.08	≤1.00	≤2.00	≤0.45	≤0.30	18.0—20.0	8.0—10.0	N	800℃
316	1.4401/1.4436	≤0.08	≤0.75	≤2.00	≤0.45	≤0.30	16.0—18.0	10.0—14.0	N:Mo	800℃
321	1.4541	≤0.08	≤0.75	≤2.00	≤0.45	≤0.30	17.0—19.0	9.0—12.0	Ti	800℃
310S	1.4845	≤0.08	≤1.50	≤2.00	≤0.45	≤0.30	24.0—26.0	19.0—22.0	—	1150℃
Inconel 601	2.4851	≤0.10	≤0.50	≤1.00	—	≤0.15	21.0—25.0	58.0—63.0	Al:Cu	1200℃
Inconel 800	1.4876	≤0.10	≤1.00	≤1.50	≤0.45	≤0.15	19.0—23.0	30.0—35.0	Al:Ti	1200℃
410S	1.4001	≤0.08	≤1.00	≤1.00	≤0.40	≤0.30	11.5—13.5	≤0.60	—	750℃
CARBON STEEL		VARIOUS								550℃

Features of Stainless Steel

SS	Features
304	Good heat resistance ,corrosion resistance ,strength at low temperature and mechanical properties, good hot working performance for example punching,bending,etc , no heat treatment influence phenomenon(nonmagnetic,U-96°C-800°C).
304L	As one kind of low carbon SS304,In the general, the similar corrosion resistance with SS 304 .But after welding or in eliminating stress, the outstanding ability of the resistance to corrosion of grain boundaries In under the condition of no-heat treatment, maintain good corrosion resistance,Used in -196°C~800°C.
316	Owing to add to Mo,So the corrosion resistance of atmospheric and high temperature strength are very good,Can be used in harsh conditions ,Processing sclerosing optimal (nonmagnetic).
316L	As one kind of low carbon series SSS316, in addition to the same feature of SS316, Optimal resistance to corrosion of grain boundaries
310S	As heat-resistant part in the under the temperature 1100°C,Oxidation stability steel ,etc

Common Specification Sheet

HESLY Flexible Metal Mesh
Model	Strips				Rod	Width	Length	Weight
Model	Depth		Thickness		Rod	Width	Length	Weight
HFM2520	25mm	1”	2.0mm	14 GA	3.0mm	1.0m	1.5m
HFM2515	25mm	1”	1.5mm	17 GA	3.0mm	1.0m	1.5m
HFM1920	19mm	3/4”	2.0mm	14 GA	3.0mm	1.0m	1.5m
HFM1915	19mm	3/4”	1.5mm	17 GA	3.0mm	1.0m	1.5m
HFM1620	16mm	5/8”	2.0mm	14 GA	3.0mm	1.0m	1.5m
HFM1615	16mm	5/8”	1.5mm	17 GA	3.0mm	1.0m	1.5m
HFM1420	14mm	9/16”	2.0mm	14 GA	3.0mm	1.0m	1.5m
HFM1415	14mm	9/16”	1.5mm	17 GA	3.0mm	1.0m	1.5m

HESLY^® Flexible Mesh
